Features
2 or 4 wire compact transmitters.
Non-contact level metering.
Narrow 5o beam angle.
PP, PVDF, PTFE, stainless steel or foam faced transducers.
Plastic or Aluminum housing.
Range : 0.1 to 1 Mtr, 2 Mtrs, 6 Mtrs, 10 Mtrs, 20 Mtrs.
Supply : 18 to 32 C DC.
Output : 4 to 20mA, Optional HART
Accuracy : ±
0.5% FS
Application
Suitable for a variety of applications including pump and compressor monitoring, refrigeration and HVAC.
Technical Specification
Pin Configuration
| Electric Connection | Micro (Contact distance 9.4mm) |
| Supply + | 1 |
| Supply - | 2 |
| Signal + (for 3 – wire) | 3 |
| Shield | Ground Pin |
